Use of strip |
|
Reverse control roll |
| Touch
type loop control |
|
 |
It
is easy to control the levelling.
A
perfect levelling control is possible.
Several straightening-support rolls are used.
The levelling roll is plated with hard chrome(Bearing steel is used.)
The use of the inverter enables continuous operation with no breakdown. |
 |
| |
Roll Diameter |
Roll Quantity |
Feeding Speed |
Coil Thickness |
Coil Width |
| MSPL-191210 |
ø12㎜ |
19 |
0 ~ 30 m/min |
0.1~1.0㎜ |
100㎜ |
| MSPL-191215 |
ø12㎜ |
19 |
0.1~1.0㎜ |
150㎜ |
| MSPL-191220 |
ø12㎜ |
19 |
0.1~0.7㎜ |
200㎜ |
| MSPL-191910 |
ø19㎜ |
19 |
0.2~2.0㎜ |
100㎜ |
MSPL-191920
|
ø19㎜ |
19 |
0.2~2.0㎜ |
200㎜ |
MSPL-191930
|
ø19㎜ |
19 |
0.2~1.6㎜ |
300㎜ |
|
| ※ It will be different or change all design or
specs to improve quality. |
